A-B 1756-ENBTThe A-B 1756-ENBT module is an Ethernet interface communication module manufactured by Rockwell Automation for communication with the ControlLogix series controllers and other automation devices. The module provides Ethernet communication capability and supports standard Ethernet communication protocols such as TCP/IP to achieve data exchange, monitoring and control operations. It is typically installed in the rack of the ControlLogix control system and is connected to the main controller via a backplane for high-speed, reliable Ethernet communication. The A-B 1756-ENBT module is widely used in the field of industrial automation and is an important component for realizing industrial automation control and monitoring.
Product parameters:
Manufacturer: Rockwell Automation
Brand: Allen-Bradley
Model: 1756-ENBT
Series: ControlLogix series
Communication protocols: Support standard Ethernet communication protocols such as TCP/IP
Communication rate: 10/100 Mbps, to meet the communication needs of industrial environments
Connection capability: 64 TCP and 128 CIP connections can be handled
Power consumption: As described in the reference information, the power consumption is about 3.7 watts 1
Current consumption: about 700 MA at 5.1 volts DC and about 3 mA at 24 volts DC 1
Heat dissipation: The heat dissipation capacity is 12.6 BTU/ hour 1
Specifications:
Dimensions: Approximately 20x30x8 inches (L x W x H) 1
Weight: About 3.2 pounds (1.45 kg) 1
Installation mode: Usually designed for rail installation, easy to deploy in the control cabinet
Housing: Housing with opening function for easy maintenance and installation
