A-B 1756-A17
The Allen-Bradley 1756-A17 is a 17-slot chassis designed by Rockwell Automation for the ControlLogix family of programmable logic controllers (PLCS). It serves as the backbone of the ControlLogix system and is used to house and connect various modules, such as processor modules, I/O modules, communication modules, etc. Through these modules, the ControlLogix system enables the control and automation of industrial processes.
Product parameters and specifications (please refer to the official documents for specific parameters)
Model: 1756-A17
Type: ControlLogix chassis
Number of slots: 17
Size: 76.2cm x 91.4cm x 20.3cm (30 in x 36 in x 8 in)
Installation mode: Horizontal installation
Power requirements: Depending on the module configured, an external power supply is usually required
Main function
Module load: 17 slots are provided for installing various ControlLogix modules.
System connection: Connect each module to achieve communication between systems.
Power distribution: Provides power for the modules installed in the chassis.
