A-B 1746-IN16 Digital input module

A-B 1746-IN16

Allen-Bradley 1746-IN16 SLC 500 16-point digital input module
1746-IN16 SLC 500 16-Point Digital Input Module
16 point digital input module
Product description

A-B	1746-IN16 Digital input module
The 1746-IN16 is a 16-point digital input module in the Allen-Bradley SLC 500 product family. It is used to receive digital signals from external devices, such as switches, sensors and encoders. The module has the following features:

16 independent digital input channels
Each channel supports DC or AC input
Programmable filtering and jitter removal

A-B	1746-IN16 Digital input module1
Supports internal or external power supplies
The 1746-IN16 is suitable for a variety of applications such as:

Process control: In applications where process parameters need to be monitored.
Machine control: In applications where machine status needs to be monitored.
Security systems: In applications where the status of security equipment needs to be monitored.
Product parameter
Parameter value
Number of channels 16
Input Type DC or AC
Voltage range 24V DC or 120V AC
Current range 2 mA to 10 mA
Accuracy ±1% full scale
Response time 1 ms
Filter programmable
