A-B 1734-OE2V
The 1734-OE2V is part of the Allen-Bradley POINT I/O family and is designed to provide two independent analog voltage output channels. The module is suitable for a variety of industrial applications, such as control indicators, frequency converters and recorders.
The features of this module include:
24V DC power supply
-10V to +10V or 0V to 10V output range
Full scale accuracy of 0.1%
Reverse polarity protection
Diagnostic light
The 1734-OE2V is available for a variety of Rockwell Automation control platforms, including ControlLogix, CompactLogix, and MicroLogix.
Product parameter
Parameter value
Power supply voltage 24V DC
Output range -10V to +10V or 0V to 10V
Accuracy 0.1% full scale
Resolution 12 bits
Response time < 2 ms
The maximum load current is 22 mA
Typical power consumption is 25 mA
Operating temperature -40°C to 70°C
Storage temperature -40°C to 85°C
Protection level IP67
Dimensions 90 x 30 x 25 mm
Weight 70 g
