A-B 1734-IE8C
The Allen-Bradley 1734-IE8C module is an analog input module designed by Rockwell Automation for the CompactLogix platform. It is mainly used to collect analog current signals from industrial sites, such as 4-20mA or 0-20mA signals from equipment such as temperature sensors and pressure sensors, and convert them into digital signals that can be recognized by PLC. This module is usually used in industrial automation system to realize the measurement and control of process variables.
Product parameters and specifications:
Model: 1734-IE8C
Type: Analog input module
Number of channels: 8
Input type: Single-end current input (0-20mA or 4-20mA)
Resolution: 16 bits
Sampling rate: Configurable
Mounting method: DIN rail mounting
Other features:
Configurable gain
Automatic zero calibration
Overload protection
Short circuit protection
Main features:
High channel number: Collect 8 analog current signals at the same time to improve efficiency.
High precision: 16 bit resolution to ensure measurement accuracy.
Flexible configuration: Parameters such as input range and sampling rate can be configured.
High reliability: Industrial grade design, suitable for harsh environments.
